Description
| General Features | |
| Flash Memory | 16M |
| Switching Capacity | 36Gbps |
| Forwarding Rate | 26.8Mpps |
| Temperature | Operating Temperature:0℃ to 50℃ Storage Temperature:-40℃ to 70℃ |
| Humdity | Operating Humidity (noncondensing):10% to 90% Storage Humidity (non-condensing): 10% to 90% |
| Dimensions | 44 x 28 x 4.4 |
| Weight | 1.91kg |
| L2 Features | |
| Auto MDI/MDIX | yes |
| Autonegotiation | yes |
| Flow Control | IEEE 802.3x for full-duplex mode Back-Pressure for half-duplex mode |
| IGMP Snooping | IGMP snooping v1/v2/v3 IGMP immediate leave Supports jumbo frames up to 10 KB |
| Immediate Leave | yes |
| Jumbo Frame | yes |
| Link Aggregation | Static Trunk IEEE 802.3ad Link Aggregation Control Protocol |
| Spanning Tree | IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) STP Auto Edge |
| VLAN | Supports 4K IEEE 802.1Q VLANs Port-based VLANs Voice VLAN Private VLAN |
| QoS Features | |
| Priority Queue Scheduling | 8 hardware queues per port |
| Rate Limiting | Ingress: Resolution 16 Kbps Egress: Resolution 16 Kbps |
| Security Features | |
| IEEE 802.1x | yes |
| IP Soruce Guard | yes |
| TACACS+ | yes |
| Management Features | |
| DHCP | Supports DHCP Client Supports DHCP Server |
| DNS | Supports DNS client, proxy |
| LLDP | yes |
| RMON | Supports RMON (groups 1, 2, 3 and 9) |
| SNMP(Agent) | SNMP v1, v2, v3 |
| Telnet | yes |
| Web Based Management | yes |
| IPv6 Features | |
| ICMPv6 | yes |
| ICMPv6 Redirect | yes |
| IPv4/IPv6 dual Protocol Stack | yes |
| IPv6 Address Types | Unicast |
| Sateless Auto-configuration | yes |
