Description
RJ-45 Interface
Eight 10/100/1000Mbps Gigabit Ethernet ports
Complies with IEEE 802.3, 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T
Supports auto MDI/MDI-X function
Switching
Hardware-based 10/100Mbps, half / full duplex and 1000Mbps full duplex mode, flow control and auto-negotiation
Features Store-and-Forward mode with wire-speed filtering and forwarding rates
IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
Integrated address look-up engine, supporting 4K absolute MAC addresses
9K Jumbo packet size
Power saving ability for Green networking
Automatic address learning and address aging
Supports CSMA/CD protocol
Hardware
Made from plastic, desktop size and wall-mount design
LED indicators for system power, per port Link / Act
5V DC, 1A external power adapter
FCC, CE Class B compliant
