Description
| General Features | |
| Physical Interface | ■ 8 10/100BASE-TX RJ-45 PoE ports |
| Feature | ■ IEEE 802.3x Flow Control ■ Auto MDI/MDI-X ■ Supports auto-negotiation of speed (10/100 Mbps) and duplex mode (half/full) ■ Wire-speed packet filtering and forwarding rate ■ Store-and-forward architecture filters fragment & CRC error packets |
| Switching Database | ■ 2K MAC address entries |
| Memory Buffer | ■ 768K Bits (96K Bytes) per device |
| Switching Capacity | ■ 1.6 Gbps |
| Electromagnetic Compatibility | ■ CE ■ FCC ■ BSMI |
| Safety | ■ LVD (EN60950) |
| Power Supply-Power Adapter | ■ AC Input: 100~240 V, 50/60Hz ■ DC Output: DC 52 V, 2.9 A |
| Temperature | Operating: 0°C~40°C (32°F~104°F) Storage: -40°C to 70°C (-40°F to 158°F) |
| Humdity | Operating: 10%-90% Relative Humidity Storage: 10%-90% Relative Humidity |
| Dimensions | ■ 280 x 179 x 44.5 mm (11.0 x 7.05 x 1.75 in) |
| Weight | ■ Weight: 1620 g (3.58 lb) |
| LED | ■ System: Power ■ Port: Link/Act, PoE, PoE Max A/B |
